Model Details

← All Products- ← Ergonomic Solutions- ← Manual Pallet Trucks -← Specialized Pallet Trucks- PM5-2748-S-Z

PM5-2748-S-Z

Printer Friendly
Available
PM5-2748-S-Z
PM5-2748-S-Z PM5-2748-S-Z PM5-2748-S-Z PM5-2748-S-Z PM5-2748-S-Z PM5-2748-S-Z

Steel Zinc Coated Pallet Truck 61 In. x 27 In. x 48 In. 5500 Lb. Capacity Silver

The specialized pallet truck is ideal for corrosive environments. The full-featured pallet truck is designed for chemical, pharmaceutical, and wash-down applications.

  • Ergonomic design requires only seventy-five (75) pounds of pulling force when fully loaded
  • Steering wheels include bearing dust covers for added life
  • Nose wheels are located on the front edge of each fork to assist in clean pallet entrance and exit
  • Chrome-plated hydraulic pump piston for long seal life
Assembled Wt.(lbs.): 158 Assembled Size: 27"W x 61"L x 48"H

Total Ship Wt.(lbs.): 211 (only 1 package) Package 1 Size: 40"W x 64"D x 23"H Color: Silver

Uniform Capacity (lb.): 5,500 Fork Spacing (in.): 27 Fork Width/Length (in.): 6-1/2 x 48
Service Range (in.): 2-7/8 to 7-3/4 Steer Caster Qty./Diameter/Width (in.): (2) 7 x 2 Steer Caster Material: Nylon
Load Roller Qty./Diameter/Width (in.): (2) 3 x 4 Load Roller Material: Nylon

Quickship Item?

Quickship Item

Can It Ship UPS/FedEx?


LTL - Must Go Truck

Image Gallery

PDF Documents

1 Year Limited Warranty

Details For Model: PM5-2748-S-Z
Available
PM5-2748-S-Z

Steel Zinc Coated Pallet Truck 61 In. x 27 In. x 48 In. 5500 Lb. Capacity Silver

The specialized pallet truck is ideal for corrosive environments. The full-featured pallet truck is designed for chemical, pharmaceutical, and wash-down applications.

  • Ergonomic design requires only seventy-five (75) pounds of pulling force when fully loaded
  • Steering wheels include bearing dust covers for added life
  • Nose wheels are located on the front edge of each fork to assist in clean pallet entrance and exit
  • Chrome-plated hydraulic pump piston for long seal life
Dimensions: 27"W x 61"L x 48"H Sell UOM: -- Color: Silver
Material: -- UPC: -- GTIN: --
Warranty: -- Shipping Weight: 211 Quickship Item? --
Can It Ship UPS? -- Option? -- Origin: --
Assembly: -- Packaging: -- Drawing Required? --
Uniform Capacity (lb.): 5,500 Fork Spacing (in.): 27 Fork Width/Length (in.): 6-1/2 x 48
Service Range (in.): 2-7/8 to 7-3/4 Steer Caster Qty./Diameter/Width (in.): (2) 7 x 2 Steer Caster Material: Nylon
Load Roller Qty./Diameter/Width (in.): (2) 3 x 4 Load Roller Material: Nylon
